Meta Ads Safe Zones: Build One Ad That Works in Every Placement

What Are Meta Ads Safe Zones?

Every Meta placement puts its own interface on top of your ad. In Reels, the bottom of the screen carries the brand name, the caption, the audio line and a Shop Now button, and the right edge carries the like, comment and share icons. In Stories, the top carries a progress bar and your profile name, and the bottom carries the call to action. These elements sit over your creative. They do not push it out of the way.

There is a second problem on top of the buttons: cropping. When a 9:16 vertical video runs in Feed, Meta shows only the middle 4:5 section. The top and bottom of your video simply do not appear.

Is Everything 4:5 Now, or Do Ads Still Get Cropped Square?

Mostly 4:5. Instagram Feed and Facebook Feed now show vertical ads at up to 4:5, so a 9:16 video loses a strip from the top and the bottom rather than being cut to a square. Feed, Reels and Stories are where most ad budgets are spent, so those are the placements to design for first.

A handful of smaller placements still show a centred square, including Facebook Marketplace, the right column on desktop and some search results. If a meaningful share of your spend lands there, move your top margin from 15% to 22% (420px on a 1920px video). If it does not, the 15% rule is enough. The placement breakdown in Ads Manager shows which applies to your account.

Why It Costs You Money

You pay for every impression whether people can read your ad or not. When the offer sits behind the Shop Now button or the logo is cropped off the top, you are paying full price for an ad that is missing its most important parts. The viewer scrolls past without knowing what you were selling or why it was worth stopping for.

It also muddies your testing. If a new creative underperforms, you want to know it was the idea, not that half the message was hidden in Reels. Getting safe zones right first means the results tell you something true about the creative.

And it is the cheapest fix in advertising. Moving a headline 300 pixels takes a designer two minutes. Finding out after a week of spend that it was covered takes a lot longer.

Safe Zone Sizes by Placement

Pixel figures are for a 1080 × 1920 video. If you design bigger, such as 1440 × 2560, use the same percentages.

Meta adds one more case: if your Reels ad carries a disclaimer or legal text, keep the bottom 40% clear rather than 35%, because the disclaimer sits above the caption.

How to Build One Ad for Every Placement

The most reliable approach is one 9:16 master, designed so the essential parts survive every crop and every overlay. You get the full-screen impact in Reels and Stories, and the Feed version keeps everything that matters. This is the method we use for our clients’ ads.

1. Start at 1080 × 1920, 9:16.Vertical gives you the most screen in Reels and Stories. Feed versions are cut from this file, so you never need a separate edit.
2. Put the overlay template on the top layer.Use the template above, or draw a box that starts 285px from the top, stops 672px from the bottom and sits 65px in from each side. Switch it off before export.
3. Fill the whole frame with picture.Background, footage, colour and texture should run right to the edges. Only the important things move inward. An ad with empty bands top and bottom looks unfinished in Reels.
4. Place the message inside the safe area.Logo, headline, offer, price, product and any face that is talking. If it would make sense on its own as a still image, it belongs inside.
5. Stack, do not spread.Work in rows inside the safe area: logo, headline, product with the offer beside it, then subtitles. Avoid putting the headline at the very top and the offer at the very bottom, which is exactly where Meta’s buttons go.
6. Keep the lower right quiet.The like, comment and share icons run down the right side of Reels. Avoid small text hard against the right edge in the lower half.
7. Let Meta’s button be the call to action.You choose the button text in Ads Manager and it always appears. Writing “Shop now” into the bottom of the video puts it right under the real button. If you want a call to action in the creative, put it inside the safe area.
8. Preview every placement before you publish.Use the preview tool above or the Ads Manager preview. If something important is covered anywhere, fix the file rather than switching that placement off.

What Goes Inside the Safe Area

A simple test: imagine the top sixth and the bottom third of the ad were painted over. Does it still make sense? If yes, it is safe. If the viewer would lose the offer, the brand or the point, move those parts in.

Rules for Video Ads

Subtitles

Most editors put subtitles low in the frame, because that is where film and TV put them. On Meta that is where the caption and the Shop Now button live. Keep the bottom of your subtitles no lower than 65% of the way down the frame (1248px on a 1920px video). Meta’s own auto-captions are placed by Meta, so you do not need to allow for those.

Supers, price cards and end cards

Check every piece of on-screen text against the safe area, not just the opening hook. End cards are the usual offender: the logo and offer are often centred on the full frame and drop straight into the caption area.

Talking heads and creator content

Frame the speaker so their face sits in the upper half of the safe area. Creators filming on their own phone tend to sit low in shot, which puts their mouth behind the caption in Reels.

Text that is part of the footage

A sign, packaging or a screen in shot cannot be moved later. If it matters, frame it inside the safe area when you film. Brief your videographer or creator with the template before the shoot, not after.

Rules for Image Ads

For a static ad running in Reels and Stories, build a 1080 × 1920 version with the same safe area. For Feed, a separate 1080 × 1350 version usually looks better than a crop, because you can rebalance the layout for the shape. In that 4:5 version keep text at least 60px from every edge.

If you only make one image, make it 9:16 with everything inside the safe area. Meta can then show it in every placement without losing anything, and you can add a 4:5 version later if the ad earns more budget.

How to Check Before You Publish

• With the preview tool on this page: drop in the export and look at all four placements at once.
• In Ads Manager: open the ad preview and step through each placement. For Reels and Stories, Ads Manager can show Meta’s own overlay so you can see exactly what is covered.
• On your phone: send the preview to your phone and look at it the way a customer would, at actual size, scrolling.
• For video, check more than one frame: the opening often passes and the end card fails. Scrub through and stop on every piece of text.

Common Mistakes

• The headline at the very top. It feels natural on a poster. In Reels and Stories it sits under the profile name, and in Feed it is cropped off.
• The offer at the very bottom. The most expensive mistake. “20% off this weekend” behind the caption means the reason to click is invisible.
• A logo in the corner. Top corners are covered in Stories and cropped in Feed. Bottom corners are covered almost everywhere.
• Designing on a desktop at full size. A 1080 × 1920 artboard on a big monitor looks spacious. On a phone with Meta’s buttons over it, it is not.
• Turning off placements to avoid the problem. Removing Reels or Stories narrows where Meta can find cheaper attention. Fixing the creative keeps every option open.
• A separate file per placement, never checked. Three files means three chances to get it wrong. One well-built master is easier to get right.

Copy-Paste Brief for Designers and Editors

Send this with any Meta ad brief. It is written so anyone making the creative, in-house or freelance, can follow it.

META AD SAFE ZONES: PLEASE FOLLOW FOR EVERY CREATIVE

Canvas: 1080 x 1920 (9:16). One master file for all placements.

Keep these OUT of the top 15% (285px), the bottom 35% (672px) and 6% (65px) in from each side:
- Logo or brand name
- Headline and hook text
- Offer, discount, price, codes and dates
- Product
- Faces, especially anyone talking
- Subtitles and on-screen text
- End card text

Background, footage and colour should still fill the whole frame. Keep small text away from the lower right, where the Reels icons sit. Do not write "Shop now" at the bottom, because Meta adds its own button there.

If we are also running square placements, move the top margin to 22% (420px).

Before sending: place the safe zone overlay on top of the export and check every frame with text, including the end card.
